This product is manufactured and designed to be compatible or used with appliances, or for selected commercial/domestic applications.

• The OP-DIN is a single-module digital din-rail timer, with l.c.d.
• 7 day / 24 hour programming capability.
• 6 on and 6 off programme spaces.

This is a high quality compatible, alternative product. It is designed to provide you with an alternative working solution to the genuine original equivalent. This alternative choice is reflected in all our compatible parts and accessories offering you a cost saving against the original product. All manufacturers’ names and numbers used for reference purposes only.

Universal products can be used for many makes and models of machine providing it matches the product type and specification. We stock and supply a wide range of universal spare parts, consumables and accessories.

The OP-DIN is a single-module digital din-rail timer, with l.c.d. And 7 day / 24 hour programming capability. There are 6 on and 6 off programme spaces. The timer has a re-chargeable cell providing battery back-up of time and pro-gramme in the event of mains failure.

• DIMENSIONS 90 x 18 x 60
• CONNECTIONS 4 X Screw terminals
• TERMINAL CAPACITY 2.5mm2 Conductor maximum
• WEIGHT 110g
• POWER CONSUMPTION 1vA @ 230V 50Hz
• RESISTIVE LOAD 16 AMPERES
• INDUCTIVE LOAD 2 AMPERES (cos Ø 0.6)
• MINIMUM LOAD 100mA @ 20v AC/DC
• TEMPERATURE RATING -10T45
• ACCURACY +/- 2.5 sec / day
• RUNNING RESERVE 100 HOURS
• MINIMUM SWITCHING 1 MINUTE
• MANUAL OVERRIDE ADVANCE ON / TIMED / ADVANCE OFF
